| Electrical Specifications: |
6C10 / 6S10 |
8C10 / 8S10 |
10C10 / 10S10 |
| 12 V DC section |
| Internal Power Bank / Battery |
Brillhaus™ AGM Sealed Lead Acid Battery |
| Internal Battery Capacity (Ah) |
100 |
| Internal Battery Voltage (V) |
12 |
| DC power socket (A) |
12 (automatic reset) |
| (Circuit breaker rating) |
| Inverter no-load current drawn (A) |
0.5 |
0.5 |
1 |
| No. of 12V DC receptacle(s) |
2 |
| Jump Starter |
900 |
900 |
1100 |
| Peak Ampere (A) |
1600 |
| Boost Ampere (A) |
1000 |
| 115/230 V AC section |
| Max. continuous AC output power (W) |
600 |
800 |
1000 |
| Surge capability (W) |
1200 |
1600 |
2000 |
| RMS AC voltage & frequency |
RMS 115 / 230 VAC +/- 5% |
| AC output waveform |
Modified Sine Wave |
| No. of AC receptacle(s) |
2 |
| Charging System: |
| AC charging current (A) |
5 (max.) |
| Peak charging voltage |
14.4 VDC |
| Charge restart voltage |
13.6 VDC |
| General Specifications: |
| Storage temperature |
-10°C~60°XC (14°F~140°F) |
| Operating temperature |
-5°C~50°C(23°F~122°F ) |
| Inverter low battery alarm alert |
10.8 VDC |
| Inverter low battery shutdown |
10.0 VDC |
| Over Voltage shutdown |
15.6 VDC |
| Overload auto shutdow |
> 600 |
> 800 |
> 1000 |
| Thermal shutdown |
> 60°C (> 140°F) |
| Dimensions (mm) |
900 / 376 x 390 x 307 |
| H(with handle) / (without handle) x W x D |
| Weight (kg) |
Approx. 39KG |
| Remarks |
Design and specifications subject to change without prior notice |
